No specification added.
| Image Sensor | 1/2.7” Progressive Scan CMOS | |
| IR Distance | • 2.8 mm Detect: 64 m (210 ft) Observe: 27 m (89 ft) Recognize: 13 m (43 ft) Identify: 6 m (20 ft) • 4 mm Detect: 80 m (262 ft) Observe: 33 m (108 ft) Recognize: 16 m (52 ft) Identify: 8 m (26 ft) | |
| Others | Max. Resolution 2688 x 1520 Main Stream • Frame Rate： 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps • Resolution: 3840x2160, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720 Sub-Stream • Frame Rate： 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps • Resolution: 704x576,640x480, 352x288, 320x240 Bit Rate Control CBR, VBR Video Compression • Main Stream: H.265+/H.265/H.264+/H.264 • Sub-Stream: H.265/H.264 H.264 Type High Profile H.264+ Main Stream Supported H.265 Type Main Profile* H.265+ Main Stream Supported* Video Bit Rate • Main Stream: 256 Kbps to 6 Mbps • Sub-Stream: 64 Kbps to 512 Kbps | |
| Lens | ||
| Type | Fixed Focal Lens | |
| Focal Length | 2.8mm 4mm | |
| Aperture | F1.6 | |
| Angle of View | • 2.8 mm: Horizontal FOV: 100°, Vertical FOV: 54°, Diagonal FOV: 118° • 4 mm: Horizontal FOV: 80.4°, Vertical FOV: 41.8°, Diagonal FOV: 98.7° | |
| Physical Specification | ||
| Dimension | 74 × 184 × 74 mm | |
| Weight | 0.525 Kg | |
| Power | • 12V DC ± 5%, Max. 10.5 W, 5.5 mm Coaxial Power Plug • PoE: 802.3af/at, class 0, Max. 11.5 W | |
| Interface | 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE | |
| Others | Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB** Built-in Microphone: Yes; Records Anything Going on within a 15-ft Radius of the Camera Built-in Speaker ALARM AND EVENT MANAGEMENT Smart Event • Human & Vehicle Classification • Intrusion Detection • Line-Crossing Detection • Region Entering Detection • Region Exiting Detection • Object Abandoned Detection • Object Removal Detection • Loitering Detection • Smart Frame • People Detection • Vehicle Detection Basic Event • Motion Detection • Video Tampering Detection • Exception ( Illegal Login) • Scene Change Detection Alarm Linkage • Memory Card Video Recording • Message Push • Audible Warning • White Light Flashing Output Notification Message Push Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS Security Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication | |
| Warranty | ||
| Warranty | 1 Year | |
| Product Code |
82517 |
|---|---|
| Product Size |
No Product Size |
| Product Color |
No Product Color |
